3BT779XP, telescopic cooker hood, BALAY

FICHA TÉCNICA

PRODUCTO

• FAMILY
• CODE 3BT779XP
• USP_MAIN
• ART_NUM 3BT779XP
• COL_BODY_HOODS Plata metalizado
• MAT_BODY Esmaltada
• COL_CHIMNEY noData
• MAT_CHIMNEY noData
• TYPOLOGY noData
• CONTROL_TYPE Mecánico
• CONSTR_TYPE noData
• INST_TYPE Integrable
• CONTROL_SETTING noData
• FRONT_PANEL_OPTIONS N/A
• MOTOR_LOCATION Motor integrado en el cuerpo de la campana
• OPERATING_MODE Convertible
• CONNECTION 240
• CURRENT 10
• VOLTAGE 220-240
• FREQUENCY 50
• CERTIFICATES
• CORD_LGTH noData
• PLUG_TYPE Schuko con conexión a tierra
• HEIGHT_WITHOUT_CHIMNEY noData
• HEIGHT noData
• WIDTH 697
• DEPTH 273
• HEIGHT_PACKED 350
• WIDTH_PACKED 800
• DEPTH_PACKED 500
• HEIGHT_NICHE_SIZE_MIN noData
• HEIGHT_NICHE_SIZE_MAX noData
• WIDTH_NICHE_SIZE_MIN 556
• WIDTH_NICHE_SIZE_MAX 556
• DEPTH_NICHE_SIZE 273
• WEIGHT_NET noData
• WEIGHT_GROSS 16.0
• AIR_EXHAUST_AVAILABLE Si
• CHIMNEY_HEIGHT_EXHAUST_MAX 475
• CHIMNEY_HEIGHT_EXHAUST_MIN 475
• CHIMNEY_HEIGHT_RECIRC_MAX 475
• CHIMNEY_HEIGHT_RECIRC_MIN 475
• ASSEMBLY_LEVEL
• ENERGY_LABEL_APPLICABLE Si
• ENERGY_CLASS_2010 E
• ENERGY_ANNUAL 179.4
• FLUID_DYNAMIC_EFFICIENCY 7.2
• FLUID_DYNAMIC_CLASS F
• LIGHT_EFFICIENCY noData
• LIGHT_CLASS E
• GREASE_FILTER_EFFICIENCY 91.2
• GREASE_FILTER_CLASS B
• AIR_FLOW_MAX noData
• AIR_FLOW_MIN noData
• AIR_FLOW_BOOST 0
• SOUND_POWER_MAX 60
• SOUND_POWER_MIN noData
• SOUND_POWER_BOOST noData
• POWER_CONS_STANDBY noData
• POWER_OFF_MODE_2010 0.00
• NOISE 60
• NOISE_BOOST noData
• ECO_LABEL
• MANUAL_CONTROL_DEVICES Interruptor deslizante
• AUTOMATIC_CONTROL_DEVICES noData
• REMOTE_CONTROL No
• MOTOR_NUMBER 2
• TOTAL_POWER_MOTORS 200
• MAX_OUTPUT_EXTRACTION noData
• BOOST_OUTPUT_EXTRACTION noData
• MAX_OUTPUT_RECIRCULATION noData
• BOOST_OUTPUT_RECIRCULATION noData
• LIGHT_CNT_TYPE Encendido/Apagado
• LIGHTS_NUMBER 2
• LAMPS_TOTAL_POWER noData
• LUMINANCE_TOTAL 339
• GREASE_FILTER_MAT Aluminio lavable
• AIR_OUTLET_DIAMETER 120 / 150
• GREASE_FILTER_TYPE noData
• NO_RETURN_FLAP Si
• ODOUR_FILTER No
• ACCESSORIES_INCL 1 x Maneta
• ACCESSORIES
• SPEED_SETTINGS noData
• LAMPS_TYPE Halógena
• PRODUCT_IMAGE .jpg
• MEASURE_IMAGE
• PANEL_IMAGE
• ADD_IMAGE1_ID
• ADD_IMAGE2_ID
• ADD_IMAGE3_ID
• ADD_IMAGE4_ID
• ADD_IMAGE5_ID
• ADD_IMAGE6_ID
• ADD_IMAGE7_ID
• ENERGY_LABEL https://media3.bsh-group.com/Documents/energylabel/es-ES/3BT779XP.pdf
• PRODUCT_FICHE https://media3.bsh-group.com/Documents/eudatasheet/es-ES/3BT779XP.pdf
